The wireless activation and time signal are transmitted from a SiteSync IQ System Controller (located high in the building for best signal coverage) to the Wireless Controller, which controls the wired clocks and bells/tones. The clock relays run one clock system (clock code 1 only) using one circuit for operation and one circuit for correction. This product is intended for use with a SiteSync IQ® Wireless Clock System.
- Control up to four circuits at up to 10 amps each (resistive)
- Clock circuits provide hourly and 12 hour correction to one wired clock system
- Bell/tone circuits feature wireless or manual activation
- Dimensions: 81/2″h x 101/8″w x 5″d
- Weight:4 lbs.
- Power: 120vac hardwired
- Operating temperature: 41° to 131° F
- Humidity: 0% – 95% Non-condensing
- Dry contacts: 10A 240v (resistive)
- Receiver frequency: 450-470 MHz (factory set)
- Paging format: POCSAG, Narrow band
- Data baud rate: 512 BPS
- Receiver sensitivity: 10uV/M
- Channel spacing: 12.5 KHz
- Warranty: 5 years
- This device is compatible with the following clocks:
-
- American Time *B & A* Series
- Cincinnati *D10 & *D12 Series
- Dukane 24SS* Series
- Edwards *010 & *012 Series
- Faraday 23770, 2372, 2380 & 2382* Series
- Simplex 77*, 82*, 2310-92* & 6310-92* Series
